Bayside Community Church is a growing multi-site church with eight campuses across the central Gulf coast of Florida. After many years as a mobile church meeting in a local school, Bayside’s West Bradenton location opened its own dedicated facility last fall. Featuring an 800-capacity main auditorium, alongside separate kids and youth spaces, the large worship center has been equipped with an extensive lighting system comprised entirely of fixtures from ADJ and sister company Elation Professional.
The job of designing and installing the whole audio, video and lighting system for the new facility was given to the Crown Design Group, which is headed up by Ben Graham and Garrett Walker. Having previously installed ADJ lighting equipment in other Bayside Community Church Campuses – including the large kids’ room at their East Bradenton location – Ben and Garrett specified more than 120 ADJ fixtures for the new West Bradenton facility, alongside a number of other products from ADJ’s sister company Elation Professional. These fixtures are spread across the main sanctuary and also the youth and kids’ halls, which both also benefit from full professional-standard production. Power draw was kept to a minimum by relying fully on LED-based fixtures, which also have the additional benefits of keeping the temperature down on stage and removing the need for regular lamp replacements.
Front lighting in the main auditorium is covered by eight of ADJ’s potent Encore FR150Z fixtures. Each featuring a 130W warm white LED engine and a large 8-inch Fresnel lens, they produce a wide, soft-edged beam that is ideal for illuminating stages.
“For the money these really are great Fresnels,” comments Graham. “They produce a really nice output and have a useful manual zoom range [8 to 50-degrees] which helped with carrying out the initial install but also means that the church has plenty of flexibility if they want to move things around in the future.”
In addition to the FR150Zs the Crown Design team also installed eighteen of ADJ’s Encore Profile 1000 Color LED-powered Ellipsoidal fixtures in front of the stage. Offering a manual zoom range of 12 to 30-degrees and harnessing the power of a 4-in-1 RGBW 120W LED light source, this is a versatile stage washing tool. “The guys at the church really like the Encore Profile 1000 Colors because they don’t just do white,” explains Graham. “As well as lighting up the stage for the sermon they can ‘double dip’ and use the same fixtures for washing the stage with color during the pre-service or portions of the worship time where they want specific colors.”
For the rig’s main moving light, ADJ’s Vizi BSW 300 was selected. Powered by a specially-designed 300W white light LED engine, this versatile fixture offers true hybrid beam, spot and wash functionality.
These key elements of the rig are augmented by twelve of Elation Professional’s SIXPAR 200 high output LED par fixtures, eight Elation Professional CUEPIX Blinder WW2 warm white stage blinders and four Elation Professional FUZE WASH Z350 quad color COB LED moving head wash fixtures. In addition, eight Elation Professional ACL 360 BAR moving ACL bar fixtures add further mid-air beam effects to round out what is a highly effective and flexible lighting rig capable of enhancing the worship experience both during high energy praise songs and slower more intimate and contemplative moments during a service.
While all of Bayside Community Church’s campuses are different in terms of their technical equipment, they do strive to create a common aesthetic and that is particularly evident in the kid’s space. One of the signature themes is exposed aluminum truss and for West Bradenton Crown Design supplied and installed a large floor-standing structure made from Global Truss America F34 quad trussing. This features a distinctive front archway, which almost touches the ceiling, and is all illuminated using ADJ’s 5P HEX LED par fixtures.
Another Bayside Kids signature is the use of ADJ’s 3D Vision panels to create a backdrop to the stage. These unique hexagonal-shaped panels are illuminated by RGB LEDs and create stunning 3D visual effects. At West Bradenton, the Crown Design team installed 27 of the panels in a trapezoidal configuration to create a vibrant backdrop to the stage. The moving heads installed in this space are ADJ’s Vizi Hex Wash7 and Focus Spot One fixtures. Each Vizi Hex Wash7 features seven 15W 6-in-1 LEDs and offers motorized zoom for a variable beam angle of between 5 and 55-degrees. Meanwhile, the Focus Spot One is an incredibly compact and affordable LED-powered moving head spot that offers a host of advanced features including motorized focus and replaceable GOBOs.
The space also features ADJ’s Saber Spot RGBW compact color mixing pinspots, which are grouped together in clusters of four and used to create midair ACL-style beam effects across the stage. The stage’s repertoire of effects is rounded out by four of ADJ’s Penta Pix units as well as two of Elation Professional’s ACL 360 BARs. Stage washing duties in this room are again covered by ADJ’s Encore Profile 1000 Color, this time paired with the smaller Encore FR50Z Fresnel fixture. With a 6-inch lens and a 50W warm white LED engine, this compact fixture is the ideal choice for illuminating smaller stages while offering all of the same features as its bigger brother.
The final worship space in the facility is the dedicated Youth room where the church’s teenagers gather for their own high octane worship sessions and dedicated bible teaching. In this space, which sits between the main auditorium and kid’s room in terms of size, stage lighting is once again handled by a combination of ADJ’s Encore Profile 1000 Color Ellipsoidals and FR150Z Fresnels. Meanwhile, warming of the six upright trusses which make up the stage set, as well as additional stage color washing, is taken care of by further ADJ 5P HEX fixtures. Midair beam effects are generated by eight ADJ Saber Spot RGBWs, grouped into two clusters of four on the outside vertical trusses, as well as four Elation Professional E Spot III moving head spot fixtures positioned on the stage itself. In addition, four Vizi Q Wash 7s are positioned on top of the four largest vertical trusses to provide additional beam effects as well as stage washes.
